Rockwell Automation Publication 22-TD001I-EN-P - June 2013 33
PowerFlex 4 and 40 AC Drives
Standard Features
• This package integrates the PowerFlex 40 Standard Drive as the base power/control component.
• Enclosure features include…
– NEMA Type 4/12 and 4X (IP66) indoor and outdoor applications
(1)
– Heat out the back design reduces enclosure size
– Viewing window-drive display and all indicators are visible.
– Mounting feet-orientation is adjustable per customer requirements
• The drive can be removed from the front of the enclosure for ease of assembly or repair.
• Low cost, highly configurable I/O inputs and/or 0…10V/4…20 mA outputs that are not used by program standard
features and options are available for customer use.
(1)
Supports indoor and outdoor applications other than direct sunlight.
Program Options
• Communication Options
– ControlNet
– DeviceNet
– EtherNet/IP
– LonWorks
– PROFIBUS DP
• Power Disconnect Options
– Drive Input Fused Disconnect Switch – 200kA short circuit withstand rating
– Motor Circuit Protector – 65kA short circuit withstand rating
• Door Mounted Operator Devices
– Hand/Off/Auto Selector Switch
– Auto/Manual Selector Switch
– Start and Stop Pushbuttons
– Forward/Reverse Selector Switch
– Local Control Off/Run Forward and Local/Remote – Selector Switches
– Local/Off/Remote Selector Switch with One – Normally Open Interposing Relay–(Panel)
– Clear Fault Push button
• Quick Disconnect
– DeviceNet Quick Disconnect–Bottom or left side mounted
• I/O Options
– DeviceNet I/O with Hand/Off auto selector switch and power disconnect auxiliary contact. (4 in / 2 out) I/O
quick disconnect optional.
– DeviceNet Point I/O with IB4 (4 in)
For option specific detail, refer to the PowerFlex 40 Adjustable Frequency AC Configured Drives Installation Instructions,
publication 23B-IN001
.
