PowerFlex 4 and 40 AC Drives
Product Selection
Drive Ratings PowerFlex 4
IP 20 Flange
Mount
(2)
(2) Meets IP40/54/65 (NEMA 1/12/4/4X) when installed in an enclosure of like rating.
PowerFlex 40
IP 66, UL Type 4X
Panel Mount
IP 20 Flange
Mount
(2)
Input Voltage kW HP
Output
Current Catalog Number
Frame
Size Catalog Number
Output
Current Catalog Number
Frame
Size Catalog Number Catalog Number
120V 50/60 Hz
1-Phase
No Filter
0.2 0.25 1.5A 22A-V1P5N104 A 22A-V1P5F104 — — — — —
0.4 0.5 2.3A 22A-V2P3N104 A 22A-V2P3F104 2.3A 22B-V2P3N104 B
22B-V2P3C104 22B-V2P3F104
0.75 1.0 4.5A 22A-V4P5N104 B 22A-V4P5F104 5.0A 22B-V5P0N104 B
22B-V5P0C104 22B-V5P0F104
1.1 1.5 6.0A 22A-V6P0N104 B 22A-V6P0F104 6.0A 22B-V6P0N104 B
22B-V6P0C104 22B-V6P0F104
240V 50/60 Hz
1-Phase
NO BRAKE
No Filter
0.2 0.25 1.4A 22A-A1P4N103 A — — — — — —
0.4 0.5 2.1A 22A-A2P1N103 A — — — — — —
0.75 1.0 3.6A 22A-A3P6N103 A — — — — — —
1.5 2.0 6.8A 22A-A6P8N103 B — — — — — —
2.2 3.0 9.6 22A-A9P6N103 B — — — — — —
240V 50/60 Hz
1-Phase
NO BRAKE
With Integral
“S Type” EMC
Filter
(1)
(1) This filter is suitable for use with a cable length of at least 10 meters for Class A and 1 meter for Class B environments.
0.2 0.25 1.4A 22A-A1P4N113 A — — — — — —
0.4 0.5 2.1A 22A-A2P1N113 A — — — — — —
0.75 1.0 3.6A 22A-A3P6N113 A — — — — — —
1.5 2.0 6.8A 22A-A6P8N113 B — — — — — —
2.2 3.0 9.6 22A-A9P6N113 B — — — — — —
240V 50/60 Hz
1-Phase
With Integral
“S Type” EMC
Filter
(1)
0.2 0.25 1.5A 22A-A1P5N114 A — — — — — —
0.4 0.5 2.3A 22A-A2P3N114 A — 2.3A 22B-A2P3N114 B — —
0.75 1.0 4.5A 22A-A4P5N114 A — 5.0A 22B-A5P0N114 B — —
1.5 2.0 8.0A 22A-A8P0N114 B — 8.0A 22B-A8P0N114 B — —
2.2 3.0 — — — — 12.0A 22B-A012N114 C— —
240V 50/60 Hz
1-Phase
No Filter
0.2 0.25 1.5A 22A-A1P5N104 A 22A-A1P5F104 —— —— —
0.4 0.5 2.3A 22A-A2P3N104 A 22A-A2P3F104 2.3A 22B-A2P3N104 B
22B-A2P3C104 22B-A2P3F104
0.75 1.0 4.5A 22A-A4P5N104 A 22A-A4P5F104 5.0A 22B-A5P0N104 B
22B-A5P0C104 22B-A5P0F104
1.5 2.0 8.0A 22A-A8P0N104 B 22A-A8P0F104 8.0A 22B-A8P0N104 B
22B-A8P0C104 22B-A8P0F104
2.2 3.0 — — — — 12.0A 22B-A012N104 C— 22B-A012F104
240V 50/60 Hz
3-Phase
No Filter
0.2 0.25 1.5A 22A-B1P5N104 A 22A-B1P5F104 —— —— —
0.4 0.5 2.3A 22A-B2P3N104 A 22A-B2P3F104 2.3A 22B-B2P3N104 B
22B-B2P3C104 22B-B2P3F104
0.75 1.0 4.5A 22A-B4P5N104 A 22A-B4P5F104 5.0A 22B-B5P0N104 B
22B-B5P0C104 22B-B5P0F104
1.5 2.0 8.0A 22A-B8P0N104 A 22A-B8P0F104 8.0A 22B-B8P0N104 B
22B-B8P0C104 22B-B8P0F104
2.2 3.0 12.0A 22A-B012N104 B 22A-B012F104 12.0A 22B-B012N104 B
22B-B012C104 22B-B012F104
3.7 5.0 17.5A 22A-B017N104 B 22A-B017F104 17.5A 22B-B017N104 B
22B-B017C104 22B-B017F104
5.5 7.5 — — — — 24.0A 22B-B024N104 C— 22B-B024F104
7.5 10.0 — — — — 33.0A 22B-B033N104 C— 22B-B033F104
480V 50/60 Hz
3-Phase
No Filter
0.4 0.5 1.4A 22A-D1P4N104 A 22A-D1P4F104 1.4A 22B-D1P4N104 B
22B-D1P4C104 22B-D1P4F104
0.75 1.0 2.3A 22A-D2P3N104 A 22A-D2P3F104 2.3A 22B-D2P3N104 B
22B-D2P3C104 22B-D2P3F104
1.5 2.0 4.0A 22A-D4P0N104 A 22A-D4P0F104 4.0A 22B-D4P0N104 B
22B-D4P0C104 22B-D4P0F104
2.2 3.0 6.0A 22A-D6P0N104 B 22A-D6P0F104 6.0A 22B-D6P0N104 B
22B-D6P0C104 22B-D6P0F104
3.7 5.0 8.7A 22A-D8P7N104 B 22A-D8P7F104 —— —— —
4.0 5.0 — — — — 10.5A 22B-D010N104 B 22B-D010C104 22B-D010F104
5.5 7.5 — — — — 12.0A 22B-D012N104 C— 22B-D012F104
7.5 10.0 — — — — 17.0A 22B-D017N104 C— 22B-D017F104
11.0 15.0 — — — — 24.0A 22B-D024N104 C— 22B-D024F104
(3)
(3) Requires use of external DC Bus Inductor or AC Line Reactor.
600V 50/60 Hz
3-Phase
No Filter
0.75 1.0 — — — — 1.7A 22B-E1P7N104 B 22B-E1P7C104 22B-E1P7F104
1.5 2.0 — — — — 3.0A 22B-E3P0N104 B 22B-E3P0C104 22B-E3P0F104
2.2 3.0 — — — — 4.2A 22B-E4P2N104 B 22B-E4P2C104 22B-E4P2F104
4.0 5.0 — — — — 6.6A 22B-E6P6N104 B 22B-E6P6C104 22B-E6P6F104
5.5 7.5 — — — — 9.9A 22B-E9P9N104 C— 22B-E9P9F104
7.5 10.0 — — — — 12.0A 22B-E012N104 C— 22B-E012F104
11.0 15.0 — — — — 19.0A 22B-E019N104 C— 22B-E019F104
Shaded areas are applicable to PowerFlex 40 only.
