PowerFlex 4 and 40 AC Drives
PowerFlex 4 and 40 Configured Drives
The heart of every Configured Drive is an Allen-Bradley standard drive. These world class products help to provide a single
solution for virtually all of your motor speed control requirements.
Configured Drive programs provide you with an offering of factory mounted options enhancing the Standard Drive
program. The options defined within the programs are pre-engineered for consistency of design. This translates to time and
money savings in set-up, integration and maintenance of your automation systems.
Catalog Number Explanation
Product Description
PowerFlex 40 Configured AC drives are ideal for OEM’s and end-users with special installation needs. Designed to meet
your customer demand for space savings, applications flexibility and reliability, the PowerFlex 40 Configured AC drive
options have been pre-engineered to ensure superior reliability.
Position
1-3 4 56-8 9 10111213141516+
23B –
D 4P0 D 1 0 4 N N – P6
abcdefghi j
a
Drive
Code Type
23B PowerFlex 40
b
Voltage Rating
Code Voltage Ph.
D 480V ac 3
c
Amp Rating
480V 60Hz Input
Code Amps kW (Hp)
1P4 1.4 0.4 (0.5)
2P3 2.3 0.75 (1.0)
4P0 4.0 1.5 (2.0)
6P0 6.0 2.2 (3.0)
010 10.5 4.0 (5.0)
012 12 5.5 (7.5)
017 17 7.5 (10)
024 24 11 (15)
d
Enclosure
Code Enclosure
C NEMA/UL Type 4X ‡
D NEMA/UL Type 4 ‡
‡ The design of the PowerFlex 40 Standard
Configured Drive supports indoor and outdoor
applications that are not in direct sunlight.
f
Emission Class
Code Rating
0 Not Filtered
g
Version
Code Version
4 RS485 (Standard)
C ControlNet
D DeviceNet
E EtherNet/IP
P PROFIBUS DP
h
Code Rating
N Reserved
i
Code Rating
N Reserved
e
HIM
Code Interface Module
1 Fixed Keypad on Drive
F
Fixed Keypad on Drive and LCD
Display with Digital Speed Control
HIM on Enclosure Door
(22-HIM-C2S)
This option changes the enclosure rating to
indoor only.
j
Options
Code Description
-E22
DeviceNet Quick Disconnect
(Bottom)
-E23
DeviceNet Quick Disconnect (Left
Side)
-P3 Motor Circuit Protector
-P3T
Motor Circuit Protector (Customer
wiring into top of device)
-P6 Disconnect Switch - Fused
-P6T
Disconnect Switch - Fused
(Customer wiring into top of device)
-R3
DeviceNet I/O (4 In/2 Out) w/Spring
Return HOA and Power Disconnect
Aux. Contact
-R4 DeviceNet Point I/O w/IB4 (4 Inputs)
-R5
-R3 plus 4 I/O Quick Disconnects
and (1) 24V DC Receptacle
-S1
Hand/Off/Auto S.S.
(Start/Stop/Speed Ref.)
-S4 Auto/Manual S.S. (Speed Ref.)
-S7 Start and Stop P.B.
-S8 Forward/Reverse S.S.
-S18
Door Mounted Local Speed Pot (1-
Tur n )
-S20
Local/Remote and Local Control
Off/Run Forward Selector Switches
-S21
Local/Off/Remote with 1 N.O.
Interposing Relay
-S22
Spring Return Hand/Off Auto S.S.
(Start/Stop/Speed Ref.)
-S23 Clear Fault P.B.
To Next Page
