Position
1-3 4 5 6-8 9 10 11 12 13-14
22A
– A 1P5 N 1 1 4 AA
ab c d e f g h
a
Drive
Code Type
22A PowerFlex 4
22B PowerFlex 40
b
Voltage Rating
Code Voltage Ph.
V 120V ac 1
A 240V ac 1
B 240V ac 3
D 480V ac 3
E 600V ac 3
c1
Rating
100-120V Single-Phase Input
Code Amps kW (Hp)
2P3 2.3 0.4 (0.5)
5P0 5.0 0.75 (1.0)
6P0 6.0 1.1 (1.5)
c2
Rating
200-240V Single-Phase Input
Code Amps kW (Hp)
2P3 2.3 0.4 (0.5)
5P0 5.0 0.75 (1.0)
8P0 8.0 1.5 (2.0)
012 12 2.2 (3.0)
c3
Rating
200-240V Three-Phase Input
Code Amps kW (Hp)
2P3 2.3 0.4 (0.5)
5P0 5.0 0.75 (1.0)
8P0 8.0 1.5 (2.0)
012 12 2.2 (3.0)
017 17.5 3.7 (5.0)
024 24 5.5 (7.5)
033 33 7.5 (10)
c4
Rating
380-480V Three-Phase Input
Code Amps kW (Hp)
1P4 1.4 0.4 (0.5)
2P3 2.3 0.75 (1.0)
4P0 4.0 1.5 (2.0)
6P0 6.0 2.2 (3.0)
010 10.5 4.0 (5.0)
012 12 5.5 (7.5)
017 17 7.5 (10)
024 24 11 (15)
c5
Rating
460-600V Three-Phase Input
Code Amps kW (Hp)
1P7 1.7 0.75 (1.0)
3P0 3.0 1.5 (2.0)
4P2 4.2 2.2 (3.0)
6P6 6.6 4.0 (5.0)
9P9 9.9 5.5 (7.5)
012 12 7.5 (10)
019 19 11 (15)
d
Enclosure
Code Enclosure
C IP66, NEMA/UL Type 4X *
F
Flange Mount - IP20, NEMA/UL
Type Open
H
Replacement Plate Drive - IP20,
NEMA/UL Type Open
Contact factory for ordering
information.
N
Panel Mount - IP20, NEMA/UL Type
Open
e
HIM
Code Interface Module
1 Fixed Keypad
f
Emission Class
Code Rating
0 Not Filtered
1 Filtered
g
Brake IGBT
Code Description
3 Without Brake
4 With Brake
h
Optional
Code Purpose
AA through ZZ
Reserved for custom
firmware
* Check availability before ordering.
