48 PowerFlex® 70 Adjustable Frequency AC Drive Installation Instructions
Parameter List
Number Parameter Name Group
1 Output Freq Metering
2 Commanded Freq Metering
3 Output Current Metering
4 Torque Current Metering
5 Flux Current Metering
6 Output Voltage Metering
7 Output Power Metering
8 Output Powr Fctr Metering
9 Elapsed MWh Metering
10 Elapsed Run Time Metering
11 MOP Frequency Metering
12 DC Bus Voltage Metering
13 DC Bus Memory Metering
14 Elapsed kWh Metering
15 Torque Estimate
3.x
Metering
16 Analog In1 Value Metering
17 Analog In2 Value Metering
22 Ramped Speed Metering
23 Speed Reference Metering
24 Commanded Torque** Metering
25 Speed Feedback Metering
26 Rated kW Drive Data
27 Rated Volts Drive Data
28 Rated Amps Drive Data
29 Control SW Ver Drive Data
40 Motor Type Motor Data
41 Motor NP Volts Motor Data
42 Motor NP FLA Motor Data
43 Motor NP Hertz Motor Data
44 Motor NP RPM Motor Data
45 Motor NP Power Motor Data
46 Mtr NP Pwr Units Motor Data
47 Motor OL Hertz Motor Data
48 Motor OL Factor Motor Data
49 Motor Poles Motor Data
50 Motor OL Mode
3.x
Motor Data
53 Motor Cntl Sel Torq Attributes
53 Torque Perf Mode Torq Attributes
54 Maximum Voltage Torq Attributes
55 Maximum Freq Torq Attributes
56 Compensation Torq Attributes
57 Flux Up Mode Torq Attributes
58 Flux Up Time Torq Attributes
59 SV Boost Filter Torq Attributes
61 Autotune Torq Attributes
62 IR Voltage Drop Torq Attributes
63 Flux Current Ref Torq Attributes
64 Ixo Voltage Drop Torq Attributes
66 Autotune Torque** Torq Attributes
67 Inertia Autotune** Torq Attributes
69 Start/Acc Boost* Volts per Hertz
70 Run Boost* Volts per Hertz
71 Break Voltage* Volts per Hertz
72 Break Frequency* Volts per Hertz
80 Feedback Select Spd Mode & Limits
80 Speed Mode Spd Mode & Limits
81 Minimum Speed Spd Mode & Limits
82 Maximum Speed Spd Mode & Limits
83 Overspeed Limit Spd Mode & Limits
84-86 Skip Frequency X Spd Mode & Limits
87 Skip Freq Band Spd Mode & Limits
88 Speed/Torque Mod** Spd Mode & Limits
90, 93 Speed Ref X Sel Speed Reference
91, 94 Speed Ref X Hi Speed Reference
92, 95 Speed Ref X Lo Speed Reference
96 TB Man Ref Sel Speed Reference
97 TB Man Ref Hi Speed Reference
98 TB Man Ref Lo Speed Reference
100 Jog Speed Discrete Speeds
100 Jog Speed 1 Discrete Speeds
101-107 Preset Speed X Discrete Speeds
108 Jog Speed 2 Discrete Speeds
116 Trim % Setpoint Speed Trim
117 Trim In Select Speed Trim
118 Trim Out Select Speed Trim
119 Trim Hi Speed Trim
120 Trim Lo Speed Trim
121 Slip RPM @ FLA Slip Comp
122 Slip Comp Gain* Slip Comp
123 Slip RPM Meter Slip Comp
124 PI Configuration Process PI
125 PI Control Process PI
126 PI Reference Sel Process PI
127 PI Setpoint Process PI
128 PI Feedback Sel Process PI
129 PI Integral Time Process PI
130 PI Prop Gain Process PI
131 PI Lower Limit Process PI
132 PI Upper Limit Process PI
133 PI Preload Process PI
134 PI Status Process PI
135 PI Ref Meter Process PI
136 PI Fdback Meter Process PI
137 PI Error Meter Process PI
138 PI Output Meter Process PI
139 PI BW Filter Process PI
140, 141 Accel Time X Ramp Rates
142, 143 Decel Time X Ramp Rates
145 DB While Stopped Stop/Brake Modes
146 S Curve % Ramp Rates
