72 Rockwell Automation Publication 750-IN100B-EN-P - July 2017
Chapter 4 Mechanical and Electrical Installation
Figure 35 - Control and Power Bay Touch Guards
Figure 36 - Wire Bay Touch Guards
M5.5
T25
2.6 N•m (23 lb•in)
Control Bay Power Bay
without DC Precharge Modules
Power Bay
with DC Precharge Modules
