Chapter 2
Programming and Parameters
This chapter provides a complete list and description of the PowerFlex 700H
parameters. The parameters can be programmed (viewed/edited) using an LCD
Human Interface Module (HIM). As an alternative, programming can also be
performed using DriveExplorer™ or DriveExecutive™ software and a personal
computer. Refer to HIM Overview
on page 81 for a brief description of the LCD
HIM.
About Parameters
To configure a drive to operate in a specific way, drive parameters may have to be
changed to values different than the default setting. Three types of parameters
exist:
•ENUM Parameters
ENUM parameters allow a selection from a list of items. The LCD HIM
will display a text message for each item.
•Bit Parameters
Bit parameters have individual bits associated with features or conditions.
If the bit is 0, the feature is off or the condition is false. If the bit is 1, the
feature is on or the condition is true.
•Numeric Parameters
These parameters have a single numerical value (i.e. 0.1 Volts).
For Information on… See page…
About Parameters Below
How Parameters are Organized 17
Monitor File 20
Motor Control File 21
Speed Command File 24
Dynamic Control File 30
Utility File 35
Communication File 45
Inputs/Outputs File 49
Parameter List by Name 56
Parameter List by Number 58
