Allen-Bradley PowerFlex 700H Programming Manual

Rockwell Automation Publication 20C-PM001F-EN-P - March 2012 17
Programming and Parameters Chapter 2
How Parameters are
Organized
The LCD HIM displays parameters in a File-Group-Parameter or Numbered
List view order. To switch display mode, access the Main Menu, press ALT, then
Sel while the cursor is on the parameter selection. In addition, using [Param
Access Lvl], you can display only the commonly used parameters or all
parameters.
File-Group-Parameter Order View
This view simplifies programming by grouping parameters that are used for
similar functions. The parameters are organized into six files in Basic Parameter
view or seven files in Advanced Parameter view. Each file is divided into groups,
and each parameter is an element in a group. By default, the LCD HIM displays
parameters by File-Group-Parameter view.
Numbered List View
In this view, all parameters are listed in ascending numerical order.
Basic Parameter View
Parameter 196 [Param Access Lvl] set to option 0 “Basic.”
File Group Parameters
Monitor
Metering Output Freq 001
Commanded Speed 002
Speed Reference 023
Commanded Torque 024
Output Current 003
Torque Current 004
DC Bus Voltage 012
Motor Control
Motor Data Motor NP Volts 041
Motor NP FLA 042
Motor NP Hertz 043
Motor NP RPM 044
Motor NP Power 045
Mtr NP Pwr Units 046
Motor OL Hertz 047
Motor Poles 049
Torq Attributes Motor Cntl Sel 053 Maximum Freq 055 Autotune 061
Speed Command
Spd Mode/Limits Speed Units 079
Feedback Select 080
Minimum Speed 081
Maximum Speed 082
Rev Speed Limit 454
Speed References Speed Ref A Sel 090
Speed Ref A Hi 091
Speed Ref A Lo 092
Speed Ref B Sel 093
Speed Ref B Hi 094
Speed Ref B Lo 095
TB Man Ref Sel 096
TB Man Ref Hi 097
TB Man Ref Lo 098
Discrete Speeds Jog Speed 1 100
Preset Speed 1 101
Preset Speed 2 102
Preset Speed 3 103
Preset Speed 4 104
Preset Speed 5 105
Preset Speed 6 106
Preset Speed 7 107
Jog Speed 2 108
Dynamic Control
Ramp Rates Accel Time 1 140
Accel Time 2 141
Decel Time 1 142
Decel Time 2 143
S-Curve % 146
Load Limits Current Lmt Sel 147 Current Lmt Val 148
Stop/Brake Modes Stop/Brk Mode A 155
Stop/Brk Mode B 156
DC Brk Lvl Sel 157
DC Brake Level 158
DC Brake Time 159
Bus Reg Mode A 161
Bus Reg Mode B 162
DB Resistor Type 163
Restart Modes Start At PowerUp 168 Auto Rstrt Tries 174 Auto Rstrt Delay 175
Power Loss Power Loss Mode 184 Power Loss Time 185 Power Loss Volts 186
Utility
Direction Config Direction Mode 190
Drive Memory Param Access Lvl 196
Reset To Defalts 197
Load Frm Usr Set 198
Save To User Set 199
Language 201
Diagnostics Start Inhibits 214 Dig In Status 216 Dig Out Status 217
Faults Fault Config 1 238
Alarms Alarm Config 1 259
Monitor
Motor Control
Speed Command
Dynamic Control
Utility
