AMX SC-N8012 User Manual

Chapter 3: Configuration Options
21
N-Command User Manual
Script Builder Page
Click Build > Script Builder to access the page shown in Figure 17. Scripts are programs you write to use over and over again. For
example, you could create scripts that shut all equipment down for the evening, putting your Encoders and Decoders in lower
power mode, turning off all TVs and lights, etc. A predefined set of commands could be created here. Basically, anything that can be
controlled with TCP commands can be controlled in this script. There are also predefined actions that you can choose (no
programming knowledge needed). Options are described in Ta bl e 11
.
NOTE: Script commands are accessible via TCP port 50020 and SSL port 50120.
FIG. 17
Script Builder Page
TABLE 11 Script Builder Option Descriptions
Option Description Notes
Script selection drop-
down
Select an existing script to load. This list shows all
scripts that were already created and saved on this unit.
Scripts are displayed in the format:
"Script ID":"Name of script"
Load button Click to load the script selected from the drop-down
(described previously).
Delete button Click to delete the selected script.
