Chapter 2 – Hardware Information 8
Maker Board UP Squared Pro 7000
UPN-ADLN01
2.3 List of Jumpers and Connectors
Please refer to the table below for all of the board’s jumpers and connectors that you
can configure for your application
Label
Function
SW1
PWR Button
CN1
RTC
CN2
M.2 2280 M-Key Slot
CN3
M.2 3052 B-Key Slot
CN4
M.2 2230 E-Key Slot
CN6
Dual LAN Port (RJ-45)
CN8
HDMI/DP Port
CN10
SATA Connector
CN11
SATA Power Connector
CN12
USB Type-C Port
CN13
Dual USB Type-A Port
CN14
USB 2.0/UART 1x10P Wafer
CN15
RS-232/422/485 1x10P Wafer (COM 1)
CN16
RS-232/422/485 1x10P Wafer (COM 2)
CN17
40-Pin HAT
CN18
CPLD and BIOS Update
CN20
DC Power Jack
CN21
Front Panel 1x6P Wafer
CN22
DC Terminal Block (Optional with Colay)
CN23
Audio Wafer
CN26
12V DC-In Connector
