Asus AAEON UP Squared Pro 7000 User Manual

Chapter 2 – Hardware Information 11
Maker Board UP Squared Pro 7000
UPN-ADLN01
Pin
Signal
Pin
Signal
Pin
Signal
55
PCIE3_CLK_DP
56
NC
57
GND
58
NC
59
NC
60
NC
61
NC
62
NC
63
NC
64
NC
65
NC
66
NC
67
NC
68
NC
69
NC
70
+3.3V
71
GND
72
+3.3V
73
GND
74
+3.3V
75
GND
2.3.4 M.2 3052 B-Key Slot (CN3)
Pin
Signal
Pin
Signal
Pin
Signal
1
NC
2
+3.3V
3
GND
4
+3.3V
5
GND
6
FULL_CARD_PWR_
OFF#(1.8V)
7
USB2_D+
8
W_DISABLE#1
9
USB2_D-
10
NC
11
GND
12
NC
13
NC
14
NC
15
NC
16
NC
17
NC
18
NC
19
NC
20
NC
21
NC
22
NC
23
NC
24
NC
25
NC
26
NC
27
GND
