Chapter 2 – Hardware Information 9
Maker Board UP Squared Pro 7000
UPN-ADLN01
Label
Function
J1
Fan Connector
JP1
AT/ATX Mode
SIM1
Nano SIM Card Connector
2.3.1 Power Button (SW1)
Switch Position
Function
SW1 1
(Default)
SW1 0
Power ON
2.3.2 RTC (CN1)
Pin
Signal
Pin
Signal
1
RTC_VCC
2
GND
