Asus M2N-L User Manual

x
M2N-L specications summary
(continued on the next page)
Processor / System Bus 1 x Socket AM2 supports:
AMD Sempron™
AMD Athlon™ 64
AMD Athlon™ 64 X2
AMD Athlon™ 64 FX
AMD Opteron™ 64 1000 series (dual core)
AMD Phenom™
Single Core/ Dual Core/Quad Core processor
HT Bus Link Speed: 2000 MT/s
AMD64 Technology
AMD Cool 'n' Quiet™ Technology
Core Logic NVIDIA
®
nForce
®
570 SLI MCP (MCP55P)
Form Factor ATX, 12 in x 9.6 in (30.5 cm x 24.5 cm)
ASUS
Features
Smart Fan Smart Fan
ASWM2.0 �
Memory Total Slots 4
Capacity Maximum up to 8GB
Memory Type Unbuffered DIMM DDR2 800/667/533 ECC/
Non-ECC
Memory Size 128MB, 256 MB, 512 MB, 1 GB, 2GB
Expansion
Slots
(follow SSI
Loacation #)
Total PCI/PCI-X/
PCIe Slots
6
Slot Location 1 1 x PCI slot (33MHz/32-bit/3.3V/PCI2.2)
Slot Location 2 1 x PCI slot (33MHz/32-bit/3.3V/PCI2.2)
Slot Location 3 1 x PCI Express x16 slot (x8 link, PCIE4)
Slot Location 4 1 x PCI Express x1 slot (x1 link)
Slot Location 5 1 x PCI Express x1 slot (x1 link)
Slot Location 6 1 x PCI Express x16 slot (x16 link, PCIE1)
Storage IDE Controller NVIDIA
®
nForce
®
570 SLI MCP (MCP55P)
- 1 x IDE connector for up to two Ultra DMA
133/100/66/33 devices
SATA Controller NVIDIA
®
nForce
®
570 SLI MCP (MCP55P)
- 6 x Serial ATA II 3.0 Gb/s devices with
RAID 0, RAID 1, RAID 0+1, RAID 5, and
JBOD congurations

Asus M2N-L Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	1
Number of SATA connectors	6
Manageability features	ASWM 2.0
Controller interface type	Serial ATA I/II
Controller 2nd interface type	UltraATA-100/133
USB 2.0 ports quantity	2
Motherboard form factor	ATX
Maximum graphics card memory	32 MB
Networking features	Dual Gigabit Ethernet
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	10 - 35 °C
RAID levels	0, 1, 0+1, JBOD
