5-10 Chapter 5: Software support
5.5 NVIDIA
®
RAID congurations
The motherboard includes a high performance SATA RAID controller integrated in
the NVIDIA
®
nForce
®
570 SLI MCP (MCP55P). It supports RAID 0, RAID 1, RAID
0+1, RAID 5, and JBOD for six independent Serial ATA disks.
The SATA ports are called channels that are associated with adapters. The rst
digit in the Location eld denes the adapter that the SATA port is associated with.
The 2nd digit denes the channel.
At the bottom section of the screen are the navigation keys. These keys allow you
to move through and select menu options.
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
RAID Mode: Striped Stripe Block: Optimal
Free Disks Array Disks
Port Disk Model Capacity Port Disk Model Capacity
1.0 XXXXXXXXXXXX XX.XXGB
1.1 XXXXXXXXXXXX XX.XXGB [→] Add
2.0 XXXXXXXXXXXX XX.XXGB
2.1 XXXXXXXXXXXX XX.XXGB
[ [←] Del
MediaShield BIOS Apr 20 2007
- Dene a New Array -
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
The navigation keys vary depending on the menu level or option.
5.5.1 Entering the NVIDIA
®
RAID Utility
To enter the NVIDIA
®
RAID Utility:
1. Restart the computer.
2. During POST, press <F10> to display the utility main menu.
The RAID BIOS setup screens shown in this section are for reference only, and
may not exactly match the items on your screen.

Asus M2N-L Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	1
Number of SATA connectors	6
Manageability features	ASWM 2.0
Controller interface type	Serial ATA I/II
Controller 2nd interface type	UltraATA-100/133
USB 2.0 ports quantity	2
Motherboard form factor	ATX
Maximum graphics card memory	32 MB
Networking features	Dual Gigabit Ethernet
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	10 - 35 °C
RAID levels	0, 1, 0+1, JBOD
