Asus M2N-L User Manual

4-20 Chapter 4: BIOS setup
4.4.3 Onboard Devices Conguration
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Allows you to select the Serial Port2 base address.
Conguration options: [Disabled] [2F8/IRQ3] [2E8/IRQ3]
Serial Port2 Mode [Normal]
Allows you to set the BIOS selection mode for Serial Port2.Conguration
options: [Normal] [IrDA] [ASK IR]
The following items appear when the Serial Port2 Mode is set to IrDA or ASK IR.
CMOS Port Dulpex Mode [Half Duplex]
Allows you to select full or half duplex for Serial Port2 (IR Mode).
Conguration options: [Half Duplex] [Full Duplex]
Onboard XGI Z9S VGA [Enabled]
Enable or disable the Onboard XGI Z9S VGA.
Conguration options: [Disabled] [Enabled]
Congure ITE8716F-S Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Congure Onboard Device
Onboard XGI Z9S VGA [Enabled]
Onboard MARVELL8056 Lan A [Enabled]
Onboard Lan BootROM [Disabled]
Onboard MARVELL8056 Lan B [Enabled]
Onboard Lan BootROM [Disabled]
Allows BIOS to Select
Serial Port1 Base
Addresses.

Asus M2N-L Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	1
Number of SATA connectors	6
Manageability features	ASWM 2.0
Controller interface type	Serial ATA I/II
Controller 2nd interface type	UltraATA-100/133
USB 2.0 ports quantity	2
Motherboard form factor	ATX
Maximum graphics card memory	32 MB
Networking features	Dual Gigabit Ethernet
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	10 - 35 °C
RAID levels	0, 1, 0+1, JBOD
