ASUS P10S-M WS Series

1-9

Chapter 1

1.2.5 Expansion slots

Unplug the power cord before adding or removing expansion cards. Failure to do so may

cause you physical injury and damage motherboard components.

Slot No. Slot Description

1 PCIE 3.0 x1_1 slot

2 PCIE 3.0 x16_1 slot

3 PCIE 3.0 x8_1 slot
