Installation & Servicing instructions ATAG iC-Range
15
9 Connecting boiler
The boiler has the following connection pipes;
- The central heating pipes.
The boiler is provided with isolation valves on the ow and return pipe to which the installation can be
connected by means of 22mm compression ttings;
- The gas pipe.
The boiler is provided with an isolation gas valve to which the gas line can be tted with 22mm
compression tting;
- The condensation drain pipe.
It consists of a 25mm exible plastic pipe. The drain pipe can be connected to this by means of an open
connection;
- The ue gas exhaust system and air supply system.
It consists of a concentric connection 60/100 mm.
- Cold and hot water pipes.
The boiler is provided with a isolation valve on the cold water inlet. The DHW installation can be
connected by means of 15mm compression ttings.
See following chapters for detailed information regarding each connection.

before connecting it to the boiler.
9.1 Central heating system
Connect the central heating system according to the current regulations.
The boiler pipes can be connected to the installation by means of 22mm compression ttings. For connecting
to thick-walled pipe (welded or tted), adapters should be used.
The boiler has a self-adjusting and self-protecting control system for the load. This involves checking the
temperature di󰀨erence between the ow and return water. Table 9.1.a shows the water displacement the
circulation pump can deliver for a particular installation resistance.
If the installation resistance is higher than the value stated, the control system will adjust the load until a
temperature di󰀨erence between ow and return water is reached that is acceptable for the control system.
When the temperature di󰀨erence still remains too high the boiler will switch itself o󰀨 and wait until the high
temperature di󰀨erential between the ow and return water has decreased again.
Pump type Grundfos UPM3 15-75
i24C i28C i36C i40C iC
Economiser 27 Plus iC Economiser 35 Plus iC Economiser 39 Plus
Water ow rate l/min 15.2 15.2 20.3 20.3 15.2 20.3 20.3
l/h 912 912 1218 1218 912 1218 1218
Permissible installation resistance kPa 25 25 20 20 25 20 20
mbar 250 250 200 200 250 200 200
Installation resistance table 9.1.a
The control system will, if an unacceptable temperature di󰀨erence is detected, repeatedly try to establish a
water ow. If this does not succeed, the boiler will block itself.


heating return as close to the boiler as possible. ATAG Heating Technology Ltd recommend the use
of the:

