Annex C Short parts list
iC Range
Description Qty ATAG Pt. No.
Heat exchanger iCon1 1 S4863100
Heat exchanger iCon2 1 S4863200
Pump Grundfos UPM3 15-75 1 S4856100
TOP HMI 1 S4916610
PCB Controler 1 S4933000
Fan iCon 1 325VDC 1 S4946500
Fan iCon 2 325VDC 1 S4946600
Expansion tank 8L 1 S4854300
Gas valve 1 S4856300
Burner complete iCon1 1 S4849100
Burner complete iCon2 1 S4849200
Plate hex iCon1 1 S4851300
Plate hex iCon2 1 S4851400
Three way valve motor 1 S4855500
Condensate tray iCon1 1 S4863400
Condensate tray iCon2 1 S4863500
Igniter & gasket 1 S4863600
DHW flow sensor 1 S4746800
Water pressure sensor 1 S4917800
Igniter transformer 1 S4851000
Cable harness combi & system 1 S4947000
Air vent 1 S4419110
Siphon complete set 1 S4863700
Igniter cables 1 S4863800
NTC flow 1 S4891600
NTC DHW 1 S4746100
Flex hose expansion vessel 1 S4856900
Maintenance Set iCon1 1 S4867900
Maintenance Set iCon2 1 S4868000
Silencer iCon 1 & 2 1 S4847800
Gasket condensate tray iCon1 1 S4854600
Gasket condensate tray iCon2 1 S4854700
NTC return 1 S4746000
Fuse 2.5 AT (250V) 2pcs 1 S4933600
Gasket pump 2pcs 1 S0009000
Clamp bar long 1 S4850900
Safety relieve valve 1 S4852500
Pressure gauge analogue 1 S4868100
Gasket set PHE (4 pcs) 1 S4743800
3 way diverter cartridge 1 S4828700
Connector OpenTherm (Blue) 1 S4745000
Connector External Safety 1 S4745200
Connector Outside Sensor (Salmon Pink) 1 S4745400
Connector ATAG zone (Orange) 1 S4920700
Connector pump (Green) 1 S4921000
Connector Y-Plan (Turquoise) 1 S4921100
Hose coupling 3/8"-Drain off 1 S4867400
Flow Restrictor 10 l/m Yellow 1 S4762000
Flow Restrictor 12 l/m Brown 1 S4748500
Flow Restrictor 15 l/m Blue 1 S4774600
Flow Restrictor 17.5 l/m Green 1 S4779600
Mains water inlet filter 1 S4878200
Flue Gas Non Return Valve 1 AA07400U
