FlexiROC T35 R/T40 R 5 Controls
69 No: 3171473547.1 en
5.2 Other controls
5.2.1 Electric cabinet
A1 electric cabinet.
1 Battery charger for remote control box batteries.
2 Settings for ECG and ECL
3 Timer diesel heater (optional)
4 PLC
5 Grease brushes (Option)
The amount of grease being pumped can be ad-
justed with the time relay K449.
The time period used is set on the upper adjust-
ment knob. It must always be 1-10 seconds.
The length of time for which the pump pulses is
adjusted on the centre adjustment knob. If the up-
per knob is at 1-10 seconds and the centre knob
is at 3 seconds then the pump operates for 3
seconds every 10th second.
