Atlas Copco PowerROC T30 E User Manual

Operator’s instructions
1. General
12
Principal components
Figure: Principal components.
Table: Principal components
Position Component Position Component
1Feed cylinder 11 Boom head
2Feeder 12 Drill support
3Rock drill 13 Track frame
4Front control panel 14 Rear control panel
5Outer boom 15 Power Pack
6Inner boom 16 Operator platform
1250 0333 26
1
19
18
17
16
15
14
13
2
3
5
6
7
8
9
10
11
12
4
