Operator’s instructions
8. Options
79
8. Options
Thread lubrication
Thread lubrication with brushes
Function
Drill steel threads are lubricated using two brushes (C) mounted on the RHS carousel
lower bracket.
Grease comes from a pump (B) located in a grease container (A) at the rear on the
right-hand side of the rig. The pump is driven by compressed air from the drill rig's
compressor.
The pump can be activated manually or automatically.
Figure: Thread lubrication system.
AGrease tank.
BPump.
CCock.
A
B
C
1250 0183 25
