Operator’s instructions
8. Options
82
Specification
Power supply 12V - 28V DC
Current usage 0.04A
Operating temperature -20 - +50 °C
Enclosing IP65
Angle measurement:
Measurement range 2 * 20°
Measurement accuracy 0.5°
Assembly and basic setting
Fit the instrument on the feeder so that it is easy to read the two displays and adjust
the sight. The brown cable connects to the drill rig's electrical system. Use a 1A fuse.
The white cable connects to ground.
Before connecting the instrument to the power supply, the instrument must be in
setup mode. This is reached by pressing the accompanying magnet towards the SE
mark on the left-hand side of the front panel. Following which, the power supply can
be connected.
When the left-hand display shows "SE 1", the instrument is in configuration mode.
There are two different configuration modes, "SE 1" and "SE 2". Switch between "SE
1" and "SE 2" by pressing the magnet towards the SE mark. The right-hand display
shows the selected values. Switch values by pressing the magnet towards the // mark.
The first configuration mode, “SE 1”, specifies the direction of the control box in
relation to the drill rig.
Tabl e: Meaning of the values shown in the right-hand display in configuration mode
“SE 1”
The instrument's resolution is specified in configuration mode “SE 2”.
When the desired values are set the power supply is switched off for 5 seconds. Fol-
lowing which, the instrument starts in normal mode.
Value Meaning
1Front of the box
forward
2Front of the box to the
right
3 Front of the box
forward
4 Front of the box to the
left
