Atlas Copco PowerROC T30 E User Manual

Operator’s instructions
1. General
14
Figure: General Description
Wagon frame with track frames
The diesel engine, chassis, dust collector, hydraulic system, air system and boom sys-
tem are mounted on the wagon frame.
Position Component
K5 Starter relay
K4 Ignition relay
K132 Safety relay
K13 Relay for hydraulic oil level
K14 Relay for compressor temperature

Atlas Copco PowerROC T30 E Specifications

General

Brand	Atlas Copco
Model	PowerROC T30 E
Category	Drill
Language	English
