Operator’s instructions
7. Drilling
72
3. Make sure that the switch for dust collector and flushing air is in ZERO position.
Rod adding
Rod adding takes place manually.
Rod adding with RHS
1. Close the upper drill steel support in order to lock the sleeve.
2. Unthread the shank adapter from the sleeve by setting the rotation lever in ROTA-
TION position and the feed lever in RETURN FEED position.
3. When the shank adapter is unthreaded, the levers for feed and rotation are set in
NEUTRAL position.
WARNING
•Danger of accidental operation
•May cause serious personal injury and
damage to property
•The operator must always control of the
rig and the remote control box
•Always check that the controls are
correctly adjusted before operating
•Always deactivate the remote control box
when not in use
•The rock drill must never be moving
during rod adding
WARNING
•Crushing hazard
•Danger of rotating parts
•Do not stay in the vicinity if the rod
grippers
