Atlas Copco STa 6000 User Manual

STa 6000 User Guide System Overview
9836 8243 01 Edition 3.1 35 (324)
2.3.4 IRC-W / IRC-B radio modules
The IRC-W Dual Band radio module / IRC-B radio module is used to interface the STa
6000 with the Printer, Torque Supervisor and ToolsTalk BLM.
It is possible to install one or two modules.
To install the IRC-W / IRC-B module, turn off the STa 6000, remove the cover and insert the IRC-W /
IRC-B module (tighten the two screws with the fingers).
After having installed the module(s) the radio module parameters must be set trough ToolsTalk BLM.
NOTE: Talking about Torque Supervisor$     Working with Torque
Supervisor
Radio 2
Radio 1
