20. TECHNICAL SPECIFICATIONS
Model: LUNA DUO-TEC MP+ 1.35 1.50 1.60 1.70
Cat. II2H3P
Gas used - G20 - G31
Rated heat input kW 34,8 46,3 56,6 66,9
Reduced heat input kW 5,1 5,1 6,3 7,4
Rated heat power 80/60°C kW 33,8 45 55 65
Rated heat power 50/30 °C kW 36,6 48,6 59,4 70,2
Reduced heat output 80/60 °C kW 5,0 5,0 6,1 7,2
Reduced heat output 50/30 °C kW 5,4 5,4 6,6 7,8
Rated efciency 50/30 °C % 105,0 105,0 105,0 105,0
Max. water pressure in heating circuit bar 4
Min. water pressure in heating circuit bar 0,5
Temperature range in heating circuit °C 25÷80
Fumes typology - C13 - C33 - C43 - C53 - C63 - C83 - C93 - B23
Coaxial ue duct diameter mm 80/125
Diameter of separate outlets mm 80/80
Max. mass ow rate of ue kg/s 0,016 0,021 0,026 0,031
Min. mass ow rate of ue kg/s 0,002 0,002 0,003 0,004
Max. temperature of ue °C 90 92 96 76
Natural gas supply pressure 2H mbar 20
Propane gas supply pressure 3P mbar 37
Power supply voltage V 230
Power supply frequency Hz 50
Rated power supply W 180 230 230 230
Net weight kg 40 40 40 50
Dimensions - height mm 766
- width mm 450
- depth mm 377 377 377 505
Protection-limit against humidity (EN 60529) - IPX5D
Capacity of boiler circuit (volume of water) l 4 4 5 6
EC certicate Nr. 0085CM0128
CONSUMPTION AT HEAT INPUT Qmax and Qmin
Qmax (G20) - 2H m
3
/h 3,68 4,90 5,98 7,07
Qmin (G20) - 2H m
3
/h 0,54 0,54 0,67 0,78
Qmax (G31) - 3P kg/h 2,70 3,60 4,40 5,20
Qmin (G31) - 3P kg/h 0,40 0,40 0,49 0,57
