Bernina 820 User Manual

109
BSR
Preparation
► use Slide-on table
► attach the desired presser foot sole to the BSR Presser
Foot
‣ removing sole: press both buttons (see arrows) on
each side of the foot
‣ slide the sole down the groove at an angle
‣ attaching the sole: slide the sole up in the groove
until it clicks into place
► attach the BSR Presser Foot to the sewing computer
and plug the cable in the outlet provided
► the «BSR» screen opens automatically
► the BSR mode 1 is activated (BSR1 is standard)
► the basic stitch length setting is 2mm
► set the desired stitch length
► when sewing small forms and stippling, stitch length of
1mm - 1.5mm is suggested
Presser Foot Pressure may be reduced
depending on the fabric type and thickness.
032298.53.04_1204_B820_EN

Bernina 820 Specifications

General

Stitch Width	9 mm
Stitch Length	6 mm
Hook System	Rotary Hook
Needle Positions	11
Screen	Color Touch Screen
Automatic Thread Cutter	Yes
Memory Function	Yes
USB Interface	Yes
Needle Threader	Yes
Start/Stop Button	Yes
Speed Control	Yes
Needle Stop Up/Down	Yes
Bobbin Winding While Sewing	Yes
Buttonhole Styles	10
Sewing Light	LED
Stitch Options	decorative
Weight	12.5 kg
Sewing Speed	1, 100 stitches per minute
