8 Value area for indicators
( 38)
9 Not included in standard
equipment
with onboard
computer
OE
Symbols explaining the
indicated value ( 32)
10 Coolant temperature dis-
play
11 Not included in standard
equipment
with onboard
computer
OE
Gear indicator, "N" is
shown for Neutral
12 Fuel level ( 32)
13 Not included in standard
equipment
with onboard
computer
OE
Value area for indicator
( 38)
14 Warning ( 22)
15 Trip odometer ( 38)
Warning lamps
Display
Warnings are displayed with the
corresponding warning lamps.
Warnings for which no separate
warning lamp is available, are in-
dicated using the 'General' warn-
ing lamp 1 in conjunction with
a warning or a warning symbol
in the multifunction display. The
universal warning lamp lights up
in either yellow or red depending
on the urgency of the warning.
Next to value area 2, warning tri-
angle 3 can be indicated in ad-
dition. These warnings alternate
with the odometers ( 38).
The universal warning lamp lights
up for the most urgent warning.
The following page contains a list
of potential warnings.
3
22
z Displays

BMW 2013 F800GT Specifications

General

Bore x Stroke	82 mm x 75.6 mm
Compression Ratio	12.0:1
Transmission	6-speed
Front Suspension	Telescopic fork, 43 mm
Rear Brakes	Single disc brake, diameter 265 mm, single-piston floating caliper
Power	90 hp (66 kW) @ 8, 000 rpm
Torque	86 Nm at 5, 800 rpm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brakes	Double disc brake, diameter 320 mm, 4-piston calipers
ABS	BMW Motorrad ABS
Seat Height	800 mm
Curb Weight	213 kg
Fuel Capacity	15 L (4.0 US gal)
Final Drive	Chain
