BMW 2013 F800GT User Manual

Press and hold button 1 until
hours 2 flash.
Press button 1 repeatedly until
desired hours are shown.
Press and hold button 1 until
minutes 3 flash.
Press button 1 repeatedly until
desired minutes are shown.
Display
Selecting display readings
Switch on ignition.
Press button 1 to select the
display in value area 2.
The following values can be indi-
cated:
Total kilometers (in illustration)
Trip odometer 1 (Trip I)
Trip odometer 2 (Trip II)
Warnings if necessary
with Tire Pressure Control
(TPC/RDC)
OE
Tire inflation pressures
with onboard computer
OE
Press button 1 to select the
display in value area 2.
The following data can be dis-
played:
Outside temperature
Average speed
Average fuel consumption
Current fuel consumption
4
38
z Operation

BMW 2013 F800GT Specifications

General

Bore x Stroke	82 mm x 75.6 mm
Compression Ratio	12.0:1
Transmission	6-speed
Front Suspension	Telescopic fork, 43 mm
Rear Brakes	Single disc brake, diameter 265 mm, single-piston floating caliper
Power	90 hp (66 kW) @ 8, 000 rpm
Torque	86 Nm at 5, 800 rpm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brakes	Double disc brake, diameter 320 mm, 4-piston calipers
ABS	BMW Motorrad ABS
Seat Height	800 mm
Curb Weight	213 kg
Fuel Capacity	15 L (4.0 US gal)
Final Drive	Chain
