tion arrows on the tires or on the
rim.
Roll front wheel into front sus-
pension (telescopic fork).
Lift front wheel and install
quick-release axle 2 with
appropriate torque.
Quick-release axle in
telescopic fork
37 lb/ft (50 Nm)
Tighten axle clamping screws 1
to appropriate torque.
Pinch bolt of quick-re-
lease axle
Tightening sequence:
tighten alternatively
14 lb/ft (19 Nm)
Remove front wheel stand.
without center stand
OE
Remove auxiliary stand.
Slide the brake calipers onto
the brake rotors.
Install screws 1 with specified
torque.
Brake caliper on fork leg
22 lb/ft (30 Nm)
Insert wheel speed sensor in
bore and install screw 1.
Remove adhesive tape from
wheel rim.
Operate brakes several times
until brake pads contact brake
disk.
Removing rear wheel
Make sure ground is level and
firm and place motorcycle
on a suitable auxiliary stand.
7
84
z Maintenance

BMW 2013 F800GT Specifications

General

Bore x Stroke	82 mm x 75.6 mm
Compression Ratio	12.0:1
Transmission	6-speed
Front Suspension	Telescopic fork, 43 mm
Rear Brakes	Single disc brake, diameter 265 mm, single-piston floating caliper
Power	90 hp (66 kW) @ 8, 000 rpm
Torque	86 Nm at 5, 800 rpm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brakes	Double disc brake, diameter 320 mm, 4-piston calipers
ABS	BMW Motorrad ABS
Seat Height	800 mm
Curb Weight	213 kg
Fuel Capacity	15 L (4.0 US gal)
Final Drive	Chain
