General instructions
The "Maintenance" chapter de-
scribes work involving the check-
ing and replacement of wear
parts that can be performed with
a minimum of effort.
If special tightening torques are
to be taken into account for
assembly, these are listed. An
overview of all required tightening
torques is contained in the
chapter "Technical Data".
Further information about main-
tenance and repair work can be
obtained on DVD through your
authorized BMW Motorrad re-
tailer.
Special tools and thorough spe-
cialized knowledge are required
to carry out some of the work. If
you are in doubt, consult a spe-
cialist service facility, preferably
your authorized BMW Motorrad
retailer.
Onboard tool kit
Standard tool kit
1 Screwdriver handle
2 Reversible screwdriver in-
sert
with Phillips PH1 and Torx
T25
Remove front and rear
turn signal bulb ( 92).
Replacing brake light and
tail light bulbs ( 91).
Remove center fairing
panel ( 93).
Remove battery ( 97).
Service tool kit
with service toolkit
OA
For more extensive work (such as
wheel removal and installation),
BMW Motorrad has put together
a service tool kit matched to your
motorcycle. You can purchase
this tool kit from your authorized
BMW Motorrad retailer.
Engine oil
Checking engine oil level
The oil level varies with
the temperature of the
oil. The higher the temperature,
7
72
z Maintenance

BMW 2013 F800GT Specifications

General

Bore x Stroke	82 mm x 75.6 mm
Compression Ratio	12.0:1
Transmission	6-speed
Front Suspension	Telescopic fork, 43 mm
Rear Brakes	Single disc brake, diameter 265 mm, single-piston floating caliper
Power	90 hp (66 kW) @ 8, 000 rpm
Torque	86 Nm at 5, 800 rpm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brakes	Double disc brake, diameter 320 mm, 4-piston calipers
ABS	BMW Motorrad ABS
Seat Height	800 mm
Curb Weight	213 kg
Fuel Capacity	15 L (4.0 US gal)
Final Drive	Chain
