BMW 2013 F800GT User Manual

Installing front and rear
turn signal bulb
Replace defective bulb.
Bulbs for flashing turn
indicators, front
RY10W / 12 V / 10 W
To prevent contaminants from
being deposited on the new
bulb's glass surface, always use
a clean, dry cloth to hold it.
Install bulb 1 by screwing
clockwise into light housing.
Insert inside end of lens into
light housing and close.
Install screw 1.
Fairings and Panels
Removing center fairing
panel
Remove seat ( 51).
Remove four screws 1 on left
and right and take off center
fairing panel.
7
93
z Maintenance

BMW 2013 F800GT Specifications

General

Bore x Stroke	82 mm x 75.6 mm
Compression Ratio	12.0:1
Transmission	6-speed
Front Suspension	Telescopic fork, 43 mm
Rear Brakes	Single disc brake, diameter 265 mm, single-piston floating caliper
Power	90 hp (66 kW) @ 8, 000 rpm
Torque	86 Nm at 5, 800 rpm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brakes	Double disc brake, diameter 320 mm, 4-piston calipers
ABS	BMW Motorrad ABS
Seat Height	800 mm
Curb Weight	213 kg
Fuel Capacity	15 L (4.0 US gal)
Final Drive	Chain
