BMW 2013 F800GT User Manual

A Engine switched off
B Operating position
Heated grips
with heated handlebar grips
OE
Operate heated grips
Start engine.
The heated grips option
can only be activated when
the engine is running.
The increase in power con-
sumption caused by the
heated grips can drain the bat-
tery if you are riding at low en-
gine speeds. If the battery is in-
adequately charged, the heated
grips are switched off to ensure
starting capability.
Press button 1 repeatedly un-
til desired heating level 2 is
shown in the display.
The handlebar grips can be
heated at two different levels.
The second level is used for
fast heat-up of the grips; then it
should be switched to the first
level.
50 % heating output
100 % heating output
If no further changes are made
the selected heating level is
adopted as the setting.
To switch off heated grips,
press button 1 repeatedly un-
til heated grip symbol 2 is not
shown anymore in the display.
BMW Motorrad ASC
with Automatic Stability Control
(ASC)
OE
Switching the ASC
function off
Switch on ignition.
The ASC function can
also be deactivated while
driving.
4
44
z Operation

BMW 2013 F800GT Specifications

General

Bore x Stroke	82 mm x 75.6 mm
Compression Ratio	12.0:1
Transmission	6-speed
Front Suspension	Telescopic fork, 43 mm
Rear Brakes	Single disc brake, diameter 265 mm, single-piston floating caliper
Power	90 hp (66 kW) @ 8, 000 rpm
Torque	86 Nm at 5, 800 rpm
Rear Suspension	Cast aluminum dual swing arm, central spring strut
Front Brakes	Double disc brake, diameter 320 mm, 4-piston calipers
ABS	BMW Motorrad ABS
Seat Height	800 mm
Curb Weight	213 kg
Fuel Capacity	15 L (4.0 US gal)
Final Drive	Chain
