BMW F 750 GS User Manual

165
Refuelling
WARNING
Fuel is highly flammable
Risk of fire and explosion
Do not smoke. Never bring
a naked flame near the fuel
tank.
WARNING
Escape of fuel due to heat-
induced expansion if fuel
tank is overfilled
Risk of falling
Do not overfill the fuel tank.
ATTENTION
Wetting of plastic surfaces
by fuel
Damage to the surfaces (sur-
faces become unsightly or
dull)
Clean plastic surfaces im-
mediately after contact with
fuel.
Make sure the ground is level
and firm and place the motor-
cycle on its side stand.
with centre stand
OE
WARNING
Fuel is highly flammable
Risk of fire and explosion
Do not smoke. Never bring
a naked flame near the fuel
tank.
WARNING
Escape of fuel due to heat-
induced expansion if fuel
tank is overfilled
Risk of falling
Do not overfill the fuel tank.
ATTENTION
Wetting of plastic surfaces
by fuel
Damage to the surfaces (sur-
faces become unsightly or
dull)
Clean plastic surfaces im-
mediately after contact with
fuel.
Make sure the ground is level
and firm and place the motor-
cycle on its centre stand.

BMW F 750 GS Specifications

General

Displacement	853 cc
Bore x Stroke	84 mm x 77 mm
Power	77 hp (57 kW) at 7, 500 rpm
Torque	83 Nm at 6, 000 rpm
Compression Ratio	12.7:1
Fuel System	Electronic fuel injection
Final Drive	Chain
Frame	Bridge-type frame, steel shell construction
ABS	BMW Motorrad ABS
Length	2, 255 mm
Width	922 mm
Height	1, 225 mm
Wheelbase	1, 559 mm
Wet Weight	224 kg
Fuel Capacity	15 liters
Tyre, Front	110/80 R19
Tyre, Rear	150/70 R17
Engine Type	Water-cooled, 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts
Clutch	Multiple-disc wet clutch, mechanically operated
Transmission	6-speed
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Double disc brake
Rear Brake	Single disc brake
Seat Height	815 mm
