BMW F 750 GS User Manual

92 OPERATION
Comfort turn indicator
If button 1 has been pressed
to the right or left, the turn
indicators are automatically
switched off under the follow-
ing circumstances:
Speed below 30 km/h: after
50 m distance covered.
Speed between 30 km/h and
100 km/h: after a speed-de-
pendent distance covered or
in case of acceleration.
Speed over 100 km/h: after
flashing five times.
If button 1 is pressed to the
right or left slightly longer, the
turn indicators only switch off
automatically once the speed-
dependent distance covered is
reached.
MULTIFUNCTION DISPLAY
Selecting reading at top
Switch on the ignition ( 78).
Short-press the MENU rocker
button at the top 1 to select
the reading in the top display
line 3.
The following values can be
displayed:
Odometer ODO
Trip distance 1 TRIP 1
Trip distance 2 TRIP 2
Automatic trip distance
TRIP A, is automatically reset
if a minimum of six hours
have passed and the date has
changed since the ignition
was switched off.
Call up the settings menu:
SETUP ENTER (is only dis-
played when the vehicle is
stationary)

BMW F 750 GS Specifications

General

Displacement	853 cc
Bore x Stroke	84 mm x 77 mm
Power	77 hp (57 kW) at 7, 500 rpm
Torque	83 Nm at 6, 000 rpm
Compression Ratio	12.7:1
Fuel System	Electronic fuel injection
Final Drive	Chain
Frame	Bridge-type frame, steel shell construction
ABS	BMW Motorrad ABS
Length	2, 255 mm
Width	922 mm
Height	1, 225 mm
Wheelbase	1, 559 mm
Wet Weight	224 kg
Fuel Capacity	15 liters
Tyre, Front	110/80 R19
Tyre, Rear	150/70 R17
Engine Type	Water-cooled, 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts
Clutch	Multiple-disc wet clutch, mechanically operated
Transmission	6-speed
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Double disc brake
Rear Brake	Single disc brake
Seat Height	815 mm
