232 ACCESSORIES
Pull red release lever 1 up.
Latching flap 2 pops up.
Fully open the latching flap.
Insert case into brackets 1
and 2 from above.
Push locking flap 1 down until
you feel some resistance.
Then push locking flap and
red release lever 2 down sim-
ultaneously.
The latching flap engages.
ATTENTION
Closure of carrying handle
with case lock latched
Damage to locking tab
Make sure that the case
lock is at right angles to the
forward direction of travel
when you close the carry
handle.
Close carry handle 1.
Turn key 2 anti-clockwise and
withdraw.
Maximum payload and
maximum speed
Note the maximum payload
and the maximum permissible
speed.

BMW F 750 GS Specifications

General

Displacement	853 cc
Bore x Stroke	84 mm x 77 mm
Power	77 hp (57 kW) at 7, 500 rpm
Torque	83 Nm at 6, 000 rpm
Compression Ratio	12.7:1
Fuel System	Electronic fuel injection
Final Drive	Chain
Frame	Bridge-type frame, steel shell construction
ABS	BMW Motorrad ABS
Length	2, 255 mm
Width	922 mm
Height	1, 225 mm
Wheelbase	1, 559 mm
Wet Weight	224 kg
Fuel Capacity	15 liters
Tyre, Front	110/80 R19
Tyre, Rear	150/70 R17
Engine Type	Water-cooled, 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts
Clutch	Multiple-disc wet clutch, mechanically operated
Transmission	6-speed
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Double disc brake
Rear Brake	Single disc brake
Seat Height	815 mm
