BMW F 750 GS User Manual

193
using a suitable auxiliary
stand.
with centre stand
OE
Make sure the ground is level
and firm and with the engine
at operating temperature,
place the motorcycle on its
centre stand.
Wait five minutes for the oil
to drain into the oil pan.
Remove oil dipstick 1.
Clean measuring area 2 with
a dry cloth
Seat the oil dipstick on the oil
filler neck, but do not engage
the threads.
Remove the oil dipstick and
check the oil level.
Engine oil, specified
level
Between MIN and MAX
marks
Engine oil, quantity for
topping up
max 0.5 l (Difference
between MIN and MAX)
If the oil level is below the MIN
mark:
Topping up the engine oil
( 194).
If the oil level is above the MAX
mark:
Have the oil level corrected
by a specialist workshop,
preferably an authorised
BMW Motorrad retailer.
Install the oil dipstick.

BMW F 750 GS Specifications

General

Displacement	853 cc
Bore x Stroke	84 mm x 77 mm
Power	77 hp (57 kW) at 7, 500 rpm
Torque	83 Nm at 6, 000 rpm
Compression Ratio	12.7:1
Fuel System	Electronic fuel injection
Final Drive	Chain
Frame	Bridge-type frame, steel shell construction
ABS	BMW Motorrad ABS
Length	2, 255 mm
Width	922 mm
Height	1, 225 mm
Wheelbase	1, 559 mm
Wet Weight	224 kg
Fuel Capacity	15 liters
Tyre, Front	110/80 R19
Tyre, Rear	150/70 R17
Engine Type	Water-cooled, 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts
Clutch	Multiple-disc wet clutch, mechanically operated
Transmission	6-speed
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Double disc brake
Rear Brake	Single disc brake
Seat Height	815 mm
