BMW R 1100 S User Manual

28
Maintenance and care
2
e Attention:
Avoid damage to brake lines,
discs and pads when installing.
Keep dirt and moisture away
from the wheel bearings.
Important for BMW Integral
ABS
OE
: do not damage the ABS
sensor cable, ABS sensor ring
or sensor.
OE
Optional extra
• Roll the front wheel in
between the fork legs
• Clean and insert spacing
bushing 7 and bearing cap 6
Looking forwards:
– left: spacing bushing 7
– right: bearing cap 6
• Clean the quick-release
axle 5, grease it and insert it
from the right, turning it
slightly at the same time
• Screw up axle bolt 3
hand-tight
• Screw up axle clamp bolts 4
handtight at left and right
• Compress the front fork firmly
several times
3
4
5
7
4
Installing the front wheel
6
20sbkg7.book Seite 28 Mittwoch, 2. Juni 2004 8:58 08

BMW R 1100 S Specifications

General

Displacement	1085 cc
Bore x Stroke	99 mm x 70.5 mm
Compression Ratio	10.3:1
Transmission	5-speed
Final Drive	Shaft drive
Fuel System	Electronic fuel injection
Rear Brakes	Single 276 mm disc, 2-piston caliper
Front Tyre	120/70 ZR 17
Rear Tyre	170/60 ZR 17
Wheelbase	1, 478 mm
Fuel Capacity	18 liters
Engine Type	Air/oil-cooled, 4-stroke, flat twin
Power	98 hp @ 7, 500 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Seat Height	810 mm
Front Brakes	Dual 305 mm discs, 4-piston calipers
