BMW R 1100 S User Manual

34
Maintenance and care
2
e Attention:
Use only wheel studs with the
same length code number.
Do not oil or grease the wheel
studs.
Avoid damage to brake lines,
brake disc, brake pads or the
wheel when installing.
Important for BMW Integral
ABS
OE
: do not damage the ABS
sensor cable, ABS sensor ring
or sensor.
OE
Optional extra
• Check that the wheel center-
ing spigot and the wheel hub
contact face are clean and
free from grease
• Important for BMW Integral
ABS
OE
, push spacing washer
3 on to the wheel centering
spigot
• Insert the rear wheel in the
centering spigot bore
• Screw in the four wheel
studs 1 with taper rings 2
hand-tight, then tighten to the
specified preload torque in
diagonally opposite sequence
• Tighten the wheel studs 1 to
final torque in diagonally
opposite sequence
Installing the rear wheel
1
2
3
20sbkg7.book Seite 34 Mittwoch, 2. Juni 2004 8:58 08

BMW R 1100 S Specifications

General

Displacement	1085 cc
Bore x Stroke	99 mm x 70.5 mm
Compression Ratio	10.3:1
Transmission	5-speed
Final Drive	Shaft drive
Fuel System	Electronic fuel injection
Rear Brakes	Single 276 mm disc, 2-piston caliper
Front Tyre	120/70 ZR 17
Rear Tyre	170/60 ZR 17
Wheelbase	1, 478 mm
Fuel Capacity	18 liters
Engine Type	Air/oil-cooled, 4-stroke, flat twin
Power	98 hp @ 7, 500 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Seat Height	810 mm
Front Brakes	Dual 305 mm discs, 4-piston calipers
