SP00D00490 2020-01-08| Robert Bosch GmbH
Introduction | ACS 763/863 | 53 en
3.6.2 Settings Menu
Function Description
Select Language Select a language from the displayed
ones. The default language is English.
Select Units To program the machine to display metric
or imperial values. The default view is in
metric system.
Date and Time To program the current time and date in
the station.
Edit Print Header Programs the information that appears
in the print summary every time the print
function is used.
Unit Activation Failure to register and activate the
machine within 30 days of initial start-
up causes the machine to lock and the
impossibility to use it. Select this item
in the Settings Menu and follow the
instructions that appear on the screen
before the trial period expires.
Oil Load Cells To enable or disable the operation of new
PAG oil, new POE oil, exhausted oil and
UV dye scales.
Refrigerant
Identifier (only for
ACS 763)
To enable or disable the purity test of the
external refrigerant identifier connected
to the USB port of the station. The
display shows three selection options:
Always Display Identifier Prompts:
displays the steps required to perform
the purity test.
Skip Display Identifier Prompts: does
not display the operations to perform
the purity test.
Ask User to connect Identifier: asks
the user, with a message, to confirm
whether or not to perform the purity
test.
Default Vacuum Leak
Test Time (except
ACS 863-OE)
To change the vacuum time for the leak
test.
Set Buzzer To enable or disable the acoustic signal.
Firmware Update To upgrade the firmware through a USB
stick or WiFi. The display shows three
selection options:
Check for Update: to check if new
firmware updates are available.
USB Update: to upgrade the firmware
through a USB stick.
Wi-Fi Update: to upgrade the firmware
through WiFi network. If the station
is connected to the WiFi network and
the WiFi network is connected to the
Internet, the search for new updates
will automatically start.
WiFi Configuration To configure the WiFi connection on the
station.The display shows five selection
options:
Search WiFi Networks: to search for
available WiFi networks.
WiFi Status: to display some data
related to the WiFi connection used.
Test WiFi connection: to perform
a connection test on the wireless
network used by the station.
Disconnect current network: to
disable the WiFi network connection
stored on the station.
Manual connect: to perform manual
scan and selection of WiFi network.
Function Description
Asanetwork To activate or deactivate the Asanetwork
function.
Information can be obtained from the
service department.
Connected Repair
[CoRe]
To activate or deactivate the CoRe
function. See Connected Repair [CoRe] in
the Initial Settings section.
Default N2
Leak Test Time
To change the N2 test time for the leak
test.
Select to return to the Setup Menu.
3.6.3 Maintenance Menu
Function Description
Filter Maintenance The filter removes acids, particles and
condensate from the refrigerant. To meet
the requirements, it is mandatory to
replace the filter after 150 kg (331 lb) of
refrigerant has been filtered.
This menu item displays the remaining
capacity of the filter before the station is
stopped and stops operating. See Filter
Maintenance in the Maintenance section.
Pump Maintenance This menu item displays the remaining
time until the next oil change of the
vacuum pump. To obtain the best
performance from the vacuum pump,
replace the oil every time the filter is
replaced. See Vacuum pump oil change in
the Maintenance section.
ISV Purge condition Displays the pressure and temperature
in the refrigerant tank. It is used to
eliminate incondensable gases and helps
to limit the pressure in the refrigerant
tank.
Calibration Check To check the calibration of the internal
scale. See Checking the calibration in the
Maintenance section of this manual.
Adjust Zero Offset To reset the new PAG oil, new POE oil,
exhausted oil and UV dye scales to zero.
Display Title Info To activate or deactivate the station
pressure and temperature displaying
.
System Information Displays the revision level of the station
software.
Periodic Leak Test Performs a pressure test to detect any
leakage on the station.
Service Menu Reserved for use by Bosch service
centers.
Production Menu Reserved for use by Bosch technicians
only.
Calibrate Air Flow To perform the air flow calibration.
Follow the instructions on the display.
Select to return to the Setup Menu.
