SP00D00490 2020-01-08| Robert Bosch GmbH
Technical data | ACS 763/863 | 83 en
10. Technical data
10.1 ACS 763/863
Characteristic Value/range
Compressor 1/4 HP
Dimensions (height x width x depth)
with HMI in shipping position
105 x 75 x 77 cm
Color LCD display with LED backlight 7" TFT WVGA (800 x 480)
Filter 150 kg (331 lb)
Humidity, RH without condensation 32,2 °C (90 °F), 86%
Gauge (EN 837-1 Class 1) Ø 100 mm
Maximum pressure (PS) 25 bar (2.5 MPa)
Sound pressure level at the operator’s
workstation according to EN ISO 11204
< 70 dB(A)
Operating voltage, Frequency 230 Vac/1, 50/60 Hz
Bottles 4x250 ml
Minimum-maximum temperature (TS) -10 °C – 120 °C
Power 1100 W
Pump capacity in free air 6 CFM (170 l/m) 50/60 Hz
Service hoses 250 cm / SAE J2888
Cylinder capacity (V) 22 l
Cylinder operating capacity 17.4 kg R1234yf
Weight (empty cylinder + accessories) 112 kg
Degree of pollution 2
Overvoltage category II
Degree of protection IP20
Refrigerant / Group R1234 / 1
WLAN (USB Dongle) WLAN 802.11 b/g
2,4 GHz
< 20 dBm
Heater belt
(only for ACS 863-OE)
230 Vac, 400 W,
60 °C thermal switch
10.2 Ambient temperature
Characteristic Value/range
Storage and transport -25 °C – 60 °C
-13 °F – 140 °F
Operation 10 °C - 50 °C
50 °F – 122 °F
10.3 Humidity
Characteristic Value/range
Storage and transport <75 %
Operation <90 %
10.4 Electromagnetic compatibility
This product complies with EMC 2014/30/EU and in
particular with EN 61326-1.
11. Glossary
A/C system:
the air conditioning system of the vehicle on which to
carry out maintenance.
Evacuation:
removal of condensate and other non-condensable
substances from an A/C system through a vacuum
pump.
Internal tank (ISV):
the refillable container of the station, intended to
contain the refrigerant; it has operational capacity of
17.4 kg.
Leak check (vacuum):
evacuation of the A/C system containing refrigerant
and pressure monitoring to detect a possible increase,
possible indication of a leak.
Rechargeable quantity:
the amount of refrigerant contained in the internal tank,
which can be loaded into the A/C system of a vehicle.
Recoverable quantity:
the total amount of additional refrigerant that can be
recovered in the internal tank.
Leak check:
pressurization of components that contain refrigerant
and pressure monitoring to detect a possible decrease,
possible indication of a leak.
Recovery / recycling:
refrigerant extraction from an A/C system, filtration and
transfer to the internal tank.
PAG / POE:
different types of oil in the vehicle A/C system
depending on the vehicle manufacturer.
R1234yf:
refrigerant.
