SP00D00490 2020-01-08| Robert Bosch GmbH
Instructions for use | ACS 763/863 | 61 en
6. Instructions for use
6.1 Entering service data
i After selecting any service function, it is possible to
enter information about the vehicle in order to allow
printing the automatically compiled final receipt.
The display shows
Enter vehicle data
Make: _________________________
Model: ________________________
Plate: ________________________
VIN: __________________________
MILEAGE: ______________________
Operator: _____________________
i Use the arrow buttons to move between the rows
and the multi touch keypad to enter the text.
1. Select
to save the data for the print report.
i This page also shows the Database icon to allow
the user to select a vehicle from the European or
Personal Database if available. If this selection is
made, the BRAND and MODEL fields will be filled
out automatically.
! Make sure to comply with the standards regarding
the protection of personal data in your state.
6.2 Refrigerant Identifier
If the internal or external refrigerant identifier,
connected to the station through the USB cable, is
installed, before performing a recovery operation,
an internal tank filling or the automatic function, the
refrigerant identifier checks the purity of the refrigerant
in the vehicle on which to carry out the operation
(during a recovery or automatic function) or in the
cylinder (when filling the internal tank).
i This procedure was written using screens related
to the recovery or automatic functions. The screens
displayed when filling the internal tank are slightly
different, although the procedure is the same.
1. The display shows REFRIGERANT IDENTIFIER
INITIALIZATION and REFRIGERANT SAMPLE
ANALYSIS
2. If the refrigerant purity test is successful, the display
shows ACCEPTABLE REFRIGERANT PURITY
" The station proceeds with the required function.
6.2.1 Unsuccessful refrigerant purity test
i If the refrigerant purity test is unsuccessful, the
station will automatically repeat the test two more
times.
1. The display shows
GAS IDENTIFICATION
REPETITION and LAST GAS IDENTIFICATION
2. The purity test is repeated.
3. If the refrigerant purity test is successful the first
or the second time, the station proceeds with the
required function.
i If the refrigerant purity test is unsuccessful for three
consecutive times, the user has the option to test
the operation of the internal refrigerant identifier in
the station or to close the function.
4. The display shows TEST FAILED PRESS OK TO
CHECK THE REFRIGERANT IDENTIFICATION
FUNCTION
5. Select to test the refrigerant identifier or to
close the function.
