Bosch B8512G User Manual

30
en | B94x Keypad operation overview Control Panels
2019.06 | 07 | F.01U.307.371 Bosch Security Systems B.V.
Description of callouts for the keypad overview figure
Callout
number
Description
1 Power indicator LED
2 Feature key (refer to Feature key, page 37)
3 Status indicators (refer to Status indicators overview, page
36)
4 Main display area (refer to Main display area, page 30)
5 Ribbon bar (refer to Ribbon bar overview, page 35)
6 Integrated proximity reader (for use with tokens and
cards)
7 Presence sensor (lights a dim screen as you approach)
Your security system provides quick access to functions through the
keypad menus.
My shortcuts are:
___________________________ ___________________________
___________________________ ___________________________
11.1 Main display area
The keypad main display area has several screens that show based on
the task performed at the keypad.

Bosch B8512G Specifications

General

Model	B8512G
Category	Control Panel
Power Supply	12 VDC
Series	G Series
Areas	8
PGM Outputs on Board	8
On-board Ethernet	Yes
Wireless Support	Yes
Manufacturer	Bosch
Input Voltage	16.5 VAC
Users	500
Communication Formats	IP, GSM, PSTN
Compatibility	Compatible with Bosch detectors, keypads, and communication modules
