English – 8
Intended use
TheLED Remote control unit is designed to control a
Bosch eBike system and control an on-board com-
puter.
TheeBike Flow app can be accessed via Bluetooth®.
Technical data
Control unit LED Remote
Product code BRC3600
Max. charging current of USB
port
mA 600
USB port charging voltage V 5
USB charging cable
A)
USB Type‑C®
B)
Charging temperature °F 32 to 104
Operating temperature °F 23 to 104
Control unit LED Remote
Storage temperature °F 50 to 104
Diagnostic interface USB Type‑C®
B)
Internal lithium-ion battery V
mAh
3.7
75
Protection rating IP54
Dimensions (without fasten-
ing)
mm 74 × 53 × 35
Weight oz 1
Bluetooth® Low Energy 5.0
– Frequency MHz 2400–2480
– Transmission power mW 1
A) Not included as part of standard delivery
B) USB Type-C® and USB-C® are trademarks of USB Imple-
menters Forum.
Operation
Prerequisites
The eBike system can only be activated when the fol-
lowing requirements are met:
– A sufficiently charged battery is inserted (see bat-
tery operating instructions).
– The speed sensor is connected properly (see drive
unit operating instructions).
Control unit power supply
If a sufficiently charged eBike battery is inserted into
the eBike and the eBike system is switched on, then
the control unit battery is powered and charged by
the eBike battery.
If the state of charge of the internal battery is very
low, you can charge the internal battery via the diag-
nostics connection(7) with a USB Type C® cable us-
ing a power bank or another suitable power source
(charging voltage5V; charging current
max.600mA).
Always close the flap of the diagnostics connec-
tion(7) so that no dust or moisture can enter.
Switching the eBike system on/off
To switch on the eBike system, briefly press the on/
off button(1). After all LEDs briefly light up, the state
of charge of the battery is displayed in color with the
battery charge indicator(3) and the set assistance
level with the(5) display. The eBike is ready to ride.
The display brightness is controlled by the ambient
light sensor(12). Therefore, do not cover the ambi-
ent light sensor(12).
The drive is activated as soon as you start pedaling
(except at assistance level OFF). The motor output
depends on the settings of the assistance level.
As soon as you stop pedaling when in normal opera-
tion, or as soon as you have reached a speed of
20mph, the eBike drive unit switches off the assis-
tance. The drive is automatically re-activated as soon
you start pedaling again and the speed is below
20mph.
To switch off the eBike system, press the on/off but-
ton(1) briefly (<3s). The battery charge indica-
tor(3) and the assistance level LED(5) go out.
If no power is drawn from the eBike drive for
about10minutes (e.g. because the eBike is not mov-
0 275 U07 3RL | (09.07.2021) Bosch eBike Systems
