Main PCB Electrical Part List

Resistors

Reference Designator Description Vendor Part Number Note

R1, R18, R19, R50, R153, R154,

R186, R235, R247, R332, R59,

R66, R160

CHIP, 100 OHM, 100PPM, +- 1%,

0603, WALS, L

T502100002399 2

R2, R17, R152, R333 CHIP, 6.8K OHM, 100PPM,

+- 1%, 0603, WALS, L, WR06X-

6801FTL

T502680102399 2

R3, R41, R131, R175 CHIP, 6.04K OHM, 100PPM, +-

1%, 0603, WALS, L

T502604102399 2

R4, R60, R603 CHIP, 2.2K, OHM, 100PPM, +-

1%, 0402, WALS, L

T502220101399 2

R5, R7, R13, R45, R110, R133,

R144, R146, R148, R178, R331,

R334, R142, R200, R211, R221

CHIP, 1M OHM, 100PPM, +- 1%,

0603, WALS, L

T502100402399 2

R6, R16, R135, R150 CHIP, 10M OHM, 100PPM, +- 1%,

0603, WALS, L

T502100502399 2

R10, R25, R113, R149 CHIP, 330 OHM, 100PPM, +- 1%,

0603, WALS, L, WR06X3300FTL

T502330002399 2

R11, R12, R31, R48, R125,

R141, R162, R174, R176, R182,

R209, R199, R204, R208, R679

CHIP, 100K OHM, 100PPM, +-

1%, 0402, WALS, L

T502100301399 2

R14, R20, R23, R27, R28, R35,

R134, R136

CHIP, 47 OHM, 100PPM, +- 1%,

0402, WALS, L

T502470A01399 2

R15, R29, R38, R43, R47, R49,

R63, R64, R76, R77, R198,

R239, R252, R269, R274, R241,

R242, R342, R346

CHIP, 1K OHM, 100PPM, +- 1%,

0402, WALS, L

T502100101399 2

R22, R53, R156, R188 CHIP, 10 OHM, 200PPM, +- 1%,

0603, WALS, L, WR06X10R0FTL

T502100A02399 2

R26, R44, R284, R291, R292,

R327, R330, R336

CHIP, 5.9K OHM, 100PPM, +-

1%, 0603, WALS, L

T502590102399 2

R32, R33, R34, R42, R286,

R290, R294, R329

CHIP, 4.42K OHM, 100PPM,

+- 1%, 0603, WALS, L, WR06X-

4421FTL

T502442102399 2

R37, R172 CHIP, 1.5K, OHM, 100PPM, +-

1%, 0603, ALS, L

T502150102399 2

R39, R40, R106, R107, R109,

R112, R116, R120

CHIP, 6.2K OHM, 100PPM, +-

1%, 0402, WALS, L

T502620101399 2

R46 CHIP, 4.32K OHM, 100PPM, +-

1%, 0402, WALS, L

T502432101399 2

R54, R55, R57, R58, R67, R68,

R82, R83, R130, R157, R212,

R276, R170, R173, R512, R513,

R514, R515, R166, R300

CHIP, 100 OHM, 100PPM, +- 1%,

0402, WALS, L, WR04X1000FTL

T502100001399 2

R56, R94, R95, R98, R103,

R126, R128, R132, R137, R138,

R151, R155, R181, R183, R190,

R243, R244, R245, R246, R306,

R310, R315, R340, R456, 139,

R145, R187, R604, R655, R656,

R158, R185

CHIP, 10K OHM, 100PPM, +- 1%,

0402, WALS, L

T502100201399 2
