Item
Number
Description Part Number Qty Note
1 FOOT, SIDE, TOP, SVCE 787744-011S 1
2 PANEL, I/O, SVCE 789257-011S 1
3 FOOT, SIDE, BOTTOM, SVCE 789360-011S 1
4 BATTERY JACK PCB 789274-002S 1
5 ASSY, PCB, DETECT POLE 789263-001S 1
6 COVER, BATTERY, SVCE 787787-011S 1
7 FOOT, BOTTOM, SVCE 787736-011S 1
8 LENS,LED,SVCE 720413-001S 1
9 WOOFER, 6IN, SVCE 789361-001S 1
10 TWIDDLER, 2.5IN, NEO, TXX
742631-0020 3
11 GRILLE, SVCE, NO LOGO 787726-011S 1
12 LOGO, S1 PRO 791175-0110 1
- S1 BATTERY PACK, SVCE 789175-001S 1
- ASSY, HARNESS, BATTERY, CLASS B 811820-001S 1
- ASSY, HARNESS, TWIDS, CLASS B 806009-002S 1
- ASSY, HARNESS, WOOFER TO BATTERY,
CLASS B
806007-002S 1
Main Assembly Parts List
6
Refer to gure 2
To Next Page
