5. DISASSEMBLY
5-10. Thread nipper mechanism
40
1. Shoulder screw
2. Thread nipper D assy
3.
Collar
4. Spacer
5. Shoulder screw
6. Thread nipper U
7.Spring
8. Screws [2 pes]
9. Plain washers
[2 pes]
10. Spring hook plate
11. Shoulder screws [2 pes]
12. Connecting plate B
13.
Set screw [loosen]
14.levershaft
15. Plain washer
16. Connecting plate
F assy
17.
Set screw [loosen]
KE-430D, BE-438D
4531Q
18. Thread nipper lever shaft
19. Washer
20. Retaining ring, E
21. Thread nipper lever
22. Set screws [2 pes:
loosen]
23. Motor lever
24. Bolts [2 pes]
25. Plain washers
[2 pes]
26. TN-motor setting plate
27. Screws
[4 pes]
28. Spring washers
(4 pes]
29. Thread nipper pulse motor assy
30. Screws with washers [2 pes]
31. TN-sensor setting plate F
32. Bolts
[2 pes]
33. Plain washers
[2 pes]
34. TN-sensor setting plate B
