6-4. Thread nipper mechanism
Apply grease to the portions indicated by the white arrows.
1. Thread nipper pulse motor assy
2. TN-motor setting plate
3.
Spring washers [4 pes]
4. Screws [4 pes]
5. Plain washers [2 pes]
6. Bolts [2 pes]
7. Motor lever
8. Set screws [2 pes]
9. TN-sensor setting plate F
10. Screws with washers [2 pes]
11. Thread nipper lever shaft
12. Retaining ring, E
46
KE·430D, BE-438D
4618Q
13.Washer
14. Thread nipper lever
15.
Set screw
16. Connecting plate F assy
17. Plain washer
18.Levershaft
19. Set screw
20. Connecting plate B
21. Shoulder screws [2 pes]
22. TN-sensor setting plate B
23. Plain washers [2 pes)
24. Bolts [2 pes]
