6. USING THE OPERATION PANEL (ADVANCED OPERATIONS)
42KE-430D, BE-438D
6-6. Using user programs
Up to 50 different combinations of settings including program no., X-scale, Y-scale, sewing speed and work clamp height can be
memorized as user programs (U1 to U50).
If you are sewing certain patterns over and over again, it is useful to record the settings for these patterns into a user program.
User programs are enabled when memory switch no. 400 is set to "ON".
<Recording the user programs>
1
Select a user program number.
TEST indicator lights
Menu indicators flash
While pressing the TEST key, press the SELECT key.
Switch to user program recording mode. Check that the
menu indicators are flashing.
User program number will appear in the PROGRAM No.
display, and “ P- - - “ will appear in the menu display.
Press the
or key to select a user program number.
2
First, set the program number.
Press the
or key to set the program number that you
would like to record.
3
Next, set the X-scale.
X-SCALE indicator flashes
Press the SELECT key.
Press the
or key to set the X-scale that you would
like to record.
4
Next, set the Y-scale.
Y-SCALE indicator flashes
Press the SELECT key.
Press the
or key to set the Y-scale that you would
like to record.
5
Next, set the sewing speed.
SPEED indicator flashes
Press the SELECT key.
Press the
or key to set the sewing speed that you
would like to record.
4469Q
4486Q
4470Q
4472Q
4474Q
