2. SPECIFICATIONS
2
KE-430D, BE-438D
2. SPECIFICATIONS
2-1. Machine specifications
1 Ordinary materials
2 Denim
7 Knitted materials
F Foundation garments
KE-430D
Electronic direct drive lockstitch bar tacker
BE-438D
Electronic direct drive lockstitch button sewer
Stitch formation Single needle lock stitch
Maximum sewing speed 3,200 rpm 2,700 rpm
Pattern size (X x Y) 40 x 30 mm max. 6.4 x 6.4 mm max.
Dimensions of buttons
that can be sewn
Outer diameter of button 8 - 30 mm (*1)
Feed mechanism
Y-î intermittent feed mechanism (pulse-motor driven mechanism)
Stitch length 0.05 - 12.7 mm
Number of stitches
Variable (Refer to "Program List" for details on the number of stitches
for sewing patterns that are already preset.)
Maximum stitch number 210,000 stitches (including 200,000 stitches which can be added)
Work clamp lifter Pulse-motor driven mechanism
Work clamp height
Button clamp height
17 mm max. 13 mm max.
Rotary hook Shuttle hook (shuttle hook 2, optional) Shuttle hook
Wiper device Standard equipment
Thread trimmer device Standard equipment
Thread nipper device Standard equipment
Data storage method Flash memory (Any sewing pattern can be added using CF card) (*2)
Number of user programs 50
Number of cycle programs 9
89 sewing patterns
are set already
53 sewing patterns
are set already
Number of stored data
(Up to 200 patterns can be added. Total number of stitches of stored data
which can be added is within 200,000.)
Motor AC servo motor 550 W
Weights
Machine head: approx. 56 kg, Operation panel: approx. 0.6 kg
Control box: 14.2 â 16.2 kg (depending on destination)
Power source
Single-phase 100V / 220V, 3-phase 200V / 220V / 380V / 400V 400VA
*1 Use the optional button clamp B (S03634-101) for diameters of 20 mm or greater.
*2 The recommended CF cards are commercially-available ones from SanDisk or HAGIWARA SYS-COM.
